Home Lift

• Capacity
• 400 kg (4 to 6 persons)

• Car Dimension
• 1100 mm x 900 mm (customizable)

• Control Device
• Other, Microprocessor based control panel

• Door Opening Size
• 700 mm

• Drive Type
• Other, Hydraulic / Traction

• Hoist Way Size
• 1550 mm x 1300 mm

• Inclination
• 0 (vertical)

• Load Capacity
• Up to 400 kg

• Machine Room Size
• Not required (machine room-less type available)

• Material
• other Sheet, Stainless steel / Powder coated steel

• Max. Lifting Height
• 12 m

• Max. Lifting Weight
• 400 kg

• Mechanism Type
• Other, Hydraulic / Traction

• Noise Level
• <60 dB

• Overhead Height
• 2700 mm

• Pit Depth
• 150 mm - 300 mm

• Power Supply
• Single phase / Three phase, 50/60 Hz

• Safety Device
• Other, Emergency lowering, overload protection, safety interlock

• Speed
• 0.3 - 0.5 m/s

• Type
• Other, Home Lift / Residential elevator

• Usage
• Other, Residential, villas, bungalows

• Voltage
• 220V / 380V

• Working Temperature
• -10C to 45C

• Capacity
• 250 kg

• Car Dimension
• 1100 mm x 900 mm

• Control Device
• Other, Microprocessor control

• Door Opening Size
• 800 mm

• Drive Type
• Other, Screw Drive

• Hoist Way Size
• 1500 mm x 1200 mm

• Inclination
• 0 (vertical lift)

• Load Capacity
• 250 kg

• Machine Room Size
• No dedicated machine room required

• Material
• other Sheet, Aluminum alloy frame, stainless steel panel

• Max. Lifting Height
• 12 m

• Max. Lifting Weight
• 250 kg

• Mechanism Type
• Other, Hydraulic or screw type

• Noise Level
• <55 dB

• Overhead Height
• 2600 mm

• Pit Depth
• 100 mm

• Power Supply
• 1.5 kW

• Safety Device
• Other, Emergency stop, door interlock, overload protection, safety sensor

• Speed
• 0.15 m/s

• Type
• Other, Compact Platform Home Lift

• Usage
• Other, Indoor & Outdoor / Residential use

• Voltage
• 220 V

• Working Temperature
• -10C to +40C

• Capacity
• 2-4 Persons Kg/day

• Car Dimension
• 900 mm x 1100 mm

• Door Opening Size
• 700 mm

• Drive Type
• Hydraulic

• Hoist Way Size
• 1400 mm x 1400 mm

• Inclination
• 0 (Vertical)

• Load Capacity
• 250-400 kg Kilograms (kg)

• Machine Room Size
• Optional / Not Required

• Material
• other Sheet

• Max. Lifting Height
• 10 meters Meter (m)

• Max. Lifting Weight
• 400 kg Kilograms (kg)

• Mechanism Type
• Other

• Noise Level
• < 60 dB db

• Overhead Height
• 2500 mm Millimeter (mm)

• Pit Depth
• 150 mm Millimeter (mm)

• Power Supply
• Single Phase / Three Phase

• Safety Device
• Safety Sensor, Overload Holding Stop

• Speed
• 0.3 m/s m/s

• Type
• Hydraulic Lift

• Voltage
• 220-240 V Volt (v)

• Working Temperature
• -10C to 45C Celsius (oC)
