Hydraulic Home Passenger Elevator

Price 800000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Hydraulic Home Passenger Elevator Specification

Car Dimension
1000 mm x 1200 mm (customizable)

Voltage
220-240 V Volt (v)

Door Opening Size
700 mm - 800 mm

Type
Hydraulic Lift

Machine Room Size
Optional / Small Room Required

Hoist Way Size
1500 mm x 1500 mm

Pit Depth
300-400 mm Millimeter (mm)

Noise Level
50 dB db

Overhead Height
3200 mm Min. Millimeter (mm)

Inclination
0

Load Capacity
320-630 kg Kilograms (kg)

Material
other Sheet

Drive Type
Other

Power Supply
Single Phase/Three Phase, 50/60 Hz

Speed
0.3-0.5 m/s m/s

Max. Lifting Height
Up to 12 meters Meter (m)

Max. Lifting Weight
630 kg Kilograms (kg)

Mechanism Type
Other

Working Temperature
0 to 40C Celsius (oC)

Safety Device
Safety Sensor, Overload Holding Stop

Capacity
2-6 Persons Kg/day

Compliance
IS 14665, EN 81-41

Door Type
Automatic / Manual

Emergency Power
Battery Backup (Optional)

Operation Panel
Touch Panel with Emergency Button

Cabin Design
Powder Coated MS / Stainless Steel with Mirror & Handrail

Landing Door
Single/Two Panel Sliding

Floor Indicator
Digital Display

Lighting
LED Lighting

Hydraulic Home Passenger Elevator Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Hydraulic Home Passenger Elevator

Explore an exceptional solution for residential mobility with our Hydraulic Home Passenger Elevator, renowned for its prodigious safety features and superlative design. This bargain offers a customizable cabin in powder-coated MS or stainless steel with a mirror and handrail, coupled with brilliant LED lighting. The elegant touch panel simplifies operation and ensures convenience, while emergency battery backup and comprehensive safety devices guarantee peace of mind. With options for automatic or manual doors, adjustable cabin dimensions, and advanced microcomputer control, this elevator is engineered for outstanding performance in any modern home.

Comprehensive Residential Usage Instructions

The Hydraulic Home Passenger Elevator is designed for residential mobility, providing seamless access between floors. It is used as a convenient transportation solution for individuals and families within homes and villas. Specifically, it serves those with mobility challenges, senior citizens, or anyone seeking comfort and sophistication in home movement. To operate, simply select your desired floor using the intuitive touch panel and enjoy a smooth, quiet ride with prodigious safety features at every instance.

Supply Capacity and Packaging - Market-Ready Offers

With consistent arrival in the market, we offer timely supply of Hydraulic Home Passenger Elevators, tailored to client needs. Our packaging guarantees the safe transit and installation of each unit, protecting every customizable feature. We provide sample availability on request, ensuring customers can evaluate quality firsthand. Benefit from our attractive offers, backed by superior market value and reliability, making us a trusted manufacturer, supplier, and service provider across India.

FAQ's of Hydraulic Home Passenger Elevator:

Q: How can I customize the Hydraulic Home Passenger Elevator for my specific requirements?

A: You can choose from a range of options, including cabin materials (powder-coated MS or stainless steel), mirror and handrail features, cabin dimensions, door type (automatic or manual), and landing door configuration. Our team guides you through the process to ensure a perfect fit for your home.

Q: What safety features are included in the elevator system?

A: The elevator is equipped with emergency lowering, overload sensor, safety locks, and an optional battery backup. These exceptional features ensure user safety, even during unexpected power outages or system faults.

Q: When should the emergency button or power backup be used?

A: The emergency button is intended for use during unforeseen circumstances, such as if the elevator stops between floors. The power backup activates automatically during power failures, allowing you to safely reach the nearest floor.

Q: Where can this elevator be installed in a residential setting?

A: The elevator can be fitted in a variety of residential properties, such as private homes, villas, or apartment penthouses. Its adaptable hoist way and machine room requirements make installation possible in many architectural layouts.

Q: What is the benefit of the microcomputer control system?

A: The microcomputer control system provides smooth, precise, and reliable operation, optimizing elevator performance and reducing noise to an impressive 50 dB, ensuring remarkable comfort and efficiency.
